Wireless Ultrasound Probe 5CP 2-in-1

Wireless Ultrasound Probe 5CP 2-in-1 - Palm Doppler Ultrasound


5CT 2-in1 Palm Doppler Ultrasound Scanner

Dual-head wireless probe: Convex / Transvaginal - Colour Doppler

Probe head R60 Convex + R13Transvaginal


Frequency:

Convex probe 3.2MHz/5MHz

Transvaginal probe 6MHz/8MHz


Scanning Depth:

Convex: 90 / 160 / 220 / 305mm

Transvaginal: 30 / 60 / 90 / 120mm


Radius & Width:

Convex 60° - 60mm

Transvaginal 149° - 13mm


Specifications

Elements: 128 elements

Scan mode: Electronic Array scanning

Screen: Smart phone or tablet screen

Supporting system: iOS, Android, Windows

Display mode: B, B / M, Colour doppler version with B+Colour, B+PDI, B+PW

Gain: 30db-105db

Dynamic Range: 40/50/60/70/80/90/100/110

Image/Video Storage: Store on mobile phones, Tablet PC

Measure: distance, area, obstetrics and other

Power: by built-in lithium battery, 4200mAh

Battery working time: 3 hours

Size: 156mm×60mm×20mm

Net Weight: 220 g

Noise reduction: 0-1-2-3-4

Channel of RF circuit board: 32

Image Adjust: BGain, TGC, DYN, Focus, Depth,  Harmonic, Denoise, Color Gain, Steer, PRF

Cineplay: auto and manual, frames can set as 100/200/500/1000

Noise reduction: 0-1-2-3-4

Dynamic Range: 40 / 50 / 60 / 70 / 80 / 90 / 100 / 110

Image / Video Storage: Store on mobile phones, Tablet PC

Measure: distance, area, obstetrics and other

Power: by built-in lithium battery, 4200mAh

Battery working time: 3 hours

Size: 156mm × 60mm × 20mm

Net Weight: 220g


Features

Puncture assist function:

In-plane puncture guide line

Out-of-plane puncture guide line

Automatic blood vessel measurement.


Warranty: 24 months, Optional: 3 years, 5 years

TGA Registered: Yes

For more information and to confirm specifications, please contact us to request a brochure.
