4RC – Bi-Plane Rectal Palm Doppler Ultrasound Scanner

Dual Transducer – Linear / Convex T-type biplane Wireless Probe – Colour Doppler

Frequency: 6.5 / 8MHz

Specifications

Scanning mode: Electronic array

Image mode: B, B/M, colour, PW, PDI

Scan Depth: 40-100mm

Image Adjust: Gain, DYN, Focus, Depth, Harmonic, Denoise

Cineplay: auto and manual, frames can set as 100/200/500/1000

Measure: Length, Area, Angle, Obstetrics

Image frame rate: 18 frames

Image save format: jpg, avi and DICOM

Battery working time：1 hour ，Use the data line for sustainable battery life

Noise reduction: 0-1-2-3-4

Dynamic Range: 40 / 50 / 60 / 70 / 80 / 90 / 100 / 110

Puncture assist function: in-plane puncture guide line function, out-of-plane puncture guide function

Charge: USB, or optional wireless charger

Length: 360mm

Gain: 30db-105db

Wifi type: 802.11g / 20MHz / 5G / 450Mbps

Working system: Android / iOS

Size: 336mm x 35mm x 28mm

Weight: 200g

TGA Registered: Yes

For more information and to confirm specifications, please contact us to request a brochure.
