SonoScape S9
The SonoScape S9 is a real time portable Colour Doppler Ultrasound machine that has a versatile imaging platform offering outstanding performance.
The S9 is embedded with SonoScape’s core imaging technology, which has significantly elevated the imaging quality to a new level and reveals more diagnostic information to the clinician. Working with the S9, you can see a clearer image, diagnose more confidently and work more comfortably.
SonoScape’s S9 offers the highest standard of ergonomics and delivers to you the latest technological innovations with highly-integrated chip sets, which enables excellent portability and flexibility. Incorporating an intelligent and style-changeable smart touch screen, the S9 has set a new standard for ultrasound scanning, which will bring you an unprecedented level of ease-of-use.
SonoScape aims to design medical equipment with state-of-the-art technology combined with optimal, ergonomic workflow. The full-sized touch panel of the S9 surpasses the hardware limitation of the traditional keyboard, allowing for easier operation.
Using the S9, you will experience a faster operation time on a variety of applications, including the most difficult of diagnostic tasks. View these programs below, and be inspired to boost your productivity.
Applications: Cardiology, Radiology, Abdominal, OBS / GYN, Small Parts, Urology, MSK, Vascular
Features:
15.6” LED Screen 50° angle
TouchScreen with 140° convertible opening angle
Two transducer sockets
Removable battery capable of 90 minutes of continuous scanning
Specifications:
Abundant Connection Interface
Multi-functional, Powerful Platform of Innovation
Stress Echo
Stress echo is the combination of 2D echocardiography with a physical or pharmacological stress, which can determine how the heart muscles respond to stress and is mainly used to diagnose and evaluate coronary artery disease. The S9’s stress echo package is a fully integrated, easily programmable interface and can be customized to your needs, delivering a streamlined workflow for wall motion scoring and reporting.
Real-time 3D (4D)
With increased physical channels and a new platform, the S9 offers both exceptional image quality and higher frame rates to meet a new standard for the SonoScape S series. Thanks to higher frame rates and advanced technologies, the 4D imaging of the S9 delivers smooth movement of the fetus and offers comprehensive 4D acquisition, data rendering, and post-processing functionality.
High Density Probe
The S9 is equipped with a high density phased array probe to meet the needs of both high frame rate and premium resolution in cardiac imaging. Thanks to the high sensitivity of SonoScape’s color Doppler mapping, the S9 provides an accurate cardiac diagnosis beyond your imagination.
Spatial Compound Imaging
Spatial Compound Imaging utilizes several lines of sight for optimal contrast resolution, speckle reduction and border detection. Making the S9 ideal for superficial and abdominal imaging with better clarity and improved continuity of structures.
Pulse Inversion Harmonic Imaging
The harmonic signals are fully preserved without degradation of acoustic information, which makes it possible for the S9 to capture high-level, detailed images and improve contrast resolution by reducing noise and clutter in the visualization of subtle lesions, small parts, vascular and so on.
C-Xlasto Elastography
SonoScape provides the S9 with a new method to support the physician in assessing tissue elasticity. The differences in tissue responses are detected and visualized in real-time by the elastography algorithms through different graphical representations, which can be particularly helpful in analyzing breast, thyroid and musculoskeletal structures.
Intuitive Graphic Ico
Guides operators in the exam mode with a single touch
Convenient Adjustment
All parameters can be adjusted easily by pressing the smart touch screen
Virtual Alphabet Keyboard
All parameters can be adjusted easily by pressing the smart touch screen
Ensures easy input of patient information and Doctor comments
Specific Application Packages
Measurement items, body marks and annotations are classified in terms of different applications
Standard Configuration
Main Unit & probes of choice, rechargeable Battery, mains adapter, Premium Hard Shell Flight Case
Optional
Stylish Trolley with adjustable height
Sturdy Suitcase in Low-pitched
Probe Options
Linear array L742(Vascular, Small parts, MSK etc.), 4-16MHz/ 38mm
Linear array L743(Vascular, Small parts, MSK etc.), 4-16MHz/ 46mm
Linear array L752(Vascular, Small parts, MSK etc.), 4-16MHz/ 52mm
Linear array 10L1 (Vascular, Small Parts, MSK etc.), 4-16MHz/ 36mm
Convex array C354 (Abdominal, Obstetrics, Gynecology), 2-6.8MHz/ R50mm
Convex array C353 (Abdominal, Obstetrics, Gynecology), 2-6.8MHz/ R55mm
Convex array C362 (Abdominal, Obstetrics, Gynecology), 2.4-5.5MHz/ R60mm
Convex array C322(Abdominal Biopsy), 2-6.8 MHz/ R20mm
Convex array C542 (Abdominal, Pediatrics), 3-6.5 MHz/ R40mm
Convex array 3C-A (Abdominal, Obstetrics, Gynecology), 1.0-7.0MHz/ R50mm
Micro-convex array C611(Cardiology, Pediatrics), 4-13 MHz/ R11mm
Micro-convex array C613(Cardiology, Pediatrics), 4-13 MHz/ R14mm
Phased array 4P-A (Cardiac, Transcranial), 1.0-5.4MHz
Phased array 5P2 (Cardiac, Transcranial, Pediatric), 2-9MHz
Phased array 8P1 (Cardiac, Transcranial, Infant), 4-16MHz
Endocavity 6V1 (Gynecology, Obstetrics, Urology), 3-15MHz/ R11mm
Endocavity 6V3 (Gynecology, Obstetrics, Urology), 3-15MHz/ R10mm
Endocavity 6V1A (Gynecology, Obstetrics, Urology), 3-15MHz/ R11mm (Vaginal Dilator: EDVS)
Endocavity 6V7 (Gynecology, Obstetrics, Urology), 3-15MHz/ R10mm
Linear array 10I2 (Intra-operative), 4-16 MHz/ 25mm
Laparoscope linear array LAP7 (Intra-operative), 3-15MHz/ 40mm
Volumetric convex array VC6-2 (Obstetrics, Abdominal, Gynecology), 2-6.8MHz/ R40mm
PWD 2.0 (Cardiac, Transcranial), 2.0Mhz
CWD 2.0 (Cardiac, Transcranial), 2.0MHz
CWD 5.0 (Cardiac, Transcranial), 5.0MHz
Transesophageal MPTEE (Cardiology), 4-13 MHz
Transesophageal MPTEE Mini (Cardiology, Pediatric), 4-13 MHz
Transrectal EC9-5 (Urology), 3-15 MHz/ R8mm
Biplane BCL10-5 (Urology), Convex 3.9-11MHz/ R10mm, Linear 6-15 MHz/ 60mm
Biplane BCC9-5 (Urology), 3.9-11 MHz/ R10mm
Warranty: 24 months, Optional: 3 years, 5 years
TGA Registered: Yes
For more information and to confirm specifications, please contact us to request a brochure.
